Australian Performance Boxes Gas Bottle Holder
Australian Performance Boxes gas bottle holders are the perfect choice for easily transporting your gas bottles around. This product has been designed for ultimate convenience and is sure to maintain your peace of mind while you’re on the road. Plus, they are 100% lightweight aluminium, making them the ideal solution for transporting your gas bottles.
Features:
- 315mm W x 450 mm H x 275mm D
- Approx 4.2kg
- Fits 4.5 kg gas bottle (check dimensions before purchase as some bottles vary)
- 3.0mm aluminium flat plate
- Safety chain
- Available in Alloy (Raw), Powder Coated Satin Traffic Black and Powder Coated Satin Signal White
Please note that freight costs will be calculated at checkout.
How to Install Your Australian Performance Boxes Jerry and/or Gas Bottle Holder
Our Australian Performance Boxes Jerry and Gas Bottle Holders offer a practical and secure solution for transporting fuel or gas bottles on your vehicle.
Please Note: Australian Performance Boxes does not offer an installation service or the M10 mounting bolts and nuts to fit the Jerry Can Holder and/or Gas Bottle Holder and will need to be purchased separately. This kit is designed for DIY installation. Please read the instructions carefully, or consult a professional if you’re unsure.
Please Note:
- These are a bolt-on attachment and do not come predrilled or with a mounting kit. We recommend using 4 x M10 bolts with a washer.
- Our Jerry Can Holders and Gas Bottle Holders can be fitted to a rear caravan bar if required; however, please note we do not supply U-bolts or mounting kits for rear bar applications.
- Avoid mounting through the jack-off points on the jack-off canopies.
Installation Instructions
Before You Start: Ensure this product is suitable for your Jerry Can or Gas Bottle. Whether mounting in the centre or off-centre, you can apply the steps below. We always recommend mounting so that the weight of the Jerry Can or Gas Bottle is supported by the tray.
1. Position, Mark & Drill: Place your Jerry Can or Gas Bottle Holder in your desired position on the back of your vehicle (centre or off-centre). Ensure the holder is square and aligned where you want it.
Mark your drilling points through the SHS (Square Hollow Section) framework if possible on the back of the canopy and the rear of your Jerry or Gas Holder. Always fix through the rear of the holder and hard into the canopy.
Please ensure when bolting to your canopy, that you do not bolt through the jack-off canopy points.
2. Fit the Bolt Assembly: For each hole, slide a washer onto an M10 bolt and through the hole and secure with an M10 Hex Nyloc Nut and tighten firmly.
3. Final Check: Double-check all bolts and nuts. Ensure the entire assembly is tight and secure, and that the Jerry Can Holder and/or Gas Bottle Holder is firmly held in place.
If you have questions or need advice about the installation process, contact the Australian Performance Boxes team. Our experts are happy to help.
